Olympus DS-9500 Digital Recorder
Olympus DS-9500 Digital Recorder
Roll over image to zoom in Click on image to zoom
Olympus DS-9500 Digital RecorderOlympus DS-9500 Digital Recorder

Olympus DS-9500 Digital Recorder

Olympus Pro RecordersSKU: DS-9500
Price:
$699.99

Description

Record your voice and manage dictation workflow with enhanced clarity and increased flexibility in any environment with the DS-9500.

With advanced features including WiFi technology, a superior noise canceling system, and enhanced structural integrity, the DS-9500 will simplify your workflow and improve dictation management efficiency. WiFi capability enables you to send dictation immediately to your transcriptionist without a USB cord, docking station, or computer. Intelligent dual microphones control the directionality to keep the focus on the person dictating and suppress ambient noise in offices, hospitals, cars, airports, and other noisy environments. A triple layer studio quality filter ensures accurate voice capture while reducing unwanted sounds including breath “pops” and wind vibrations. This ensures superior accuracy and enhanced workflow efficiency.

Encapsulated in a 1.5 – meter (4.9-ft) shockproof, alcohol wipe resistant body and equipped with an optical slide switch, the DS-9500 is designed to be a strong and dependable workhorse in heavy use environments. Complete with 256 bit AES encryption and device pin lock, the DS-9500 provides trusted security for your most sensitive information.

  • WiFi compatible for immediate file sharing with transcriptionist
  • Intelligent dual microphones suppress unwanted background noise
  • Triple-layer sound studio pop filter blocks breath and wind vibrations
  • Certified up to 1.5 meter shockproof body
  • Precise slide switch (REC / STOP / PLAY / REW)
  • Full Color TFT LCD with white LED backlight, 36.72mm x 48.96mm / 2.4 inch (240 x 320 pixels)
  • Rechargeable Li-ion-battery (1350mAh)
  • Storage media: Secure Digital (SD, SDHC), 2GB, 32GB (External)
  • Internal storage media: 2GB (micro SD), DSS Pro SP = approx. 306 hours recording time
Recording Formats
  • DSS / DSS Pro / WAV / MP3
Professional Speech Processing
  • Author IDs: 10
  • Worktypes: 20
  • Priority: High/Normal
  • Verbal comments (up to 32 per file), Text editor, Pending, File lock
Advanced Recording Features
  • Voice activated recording (VCVA)
  • Microphone sensitivity: 3 Levels (High/Middle/Low)(Conference Mode = Auto)
  • Insert, Overwrite, Append, Partially erase: Only with DSS Pro & DSS (Overwrite & Append: also WAV)
  • Index Marks Per File: 32 (DSS Pro/WAV/MP3), 16 (DSS)
  • Level meter, VCVA indicator
  • Folders: Up to 7 (name changeable)
  • Hands-free dictation, stand-alone transcription with optional Olympus Footswitch RS-31
  • Full-duplex recording with headphones
Playback
  • Speed: Slow/Normal/Fast
  • Volume level: Adjustable from 0 to 30
  • Cue / Review
Stationary Operations
  • Applicable as PC microphone
  • Controlling PC application ODMS
Administrative Settings
  • Accessibility: Various settings related to user authorization, e.g., prohibiting erasing of files; menu settings
  • Splash message: Option to set personalized welcome message during start-up
  • Main button guide: Shows current slide switch function on display
  • Alarms: Option to set alarms for particular occasions; beeping noise
  • Customizable display content: Option to customize information shown on display
  • Programmable buttons: 3
  • Single user and workgroup installation
  • Server installations including license manager and manager tools (optional)
  • Citrix / WTS / Thin client support
Technical Data
  • Dimensions: 4.75 in (H) x 1.96 in (W) x .73 in (D) weight: 4.1 oz. (including battery)
  • Languages: English, German, Czech, Spanish, French, Danish, Dutch, Polish, Russian, Swedish, Italian
  • Operating systems: Microsoft Windows ( 7, 8.1, 10) | Mac OS X (10.10-10.13)
  • Recommended operating condition: 0-42°C / 32-107.6°F
  • Mini USB 2.0 composite / storage class
  • Charging via AC adapter or USB
  • Speaker (integrated): Built-in .43 x .59 in square dynamic speaker, 320mW (8Ω speaker)
  • Headphone/microphone jacks: Ø3.5mm mini jack | impedance 2kΩ, Ø3.5mm mini jack | impedance 8Ω or more
Available Accessories
  • LI-92B Li-ion battery
  • CR-21 Docking Station
  • AS-9000 PC transcription kit with RS31 footswitch
  • Warranty card
  • Instruction manual
  • LI-92B Lithium-ion rechargeable battery,
  • A-517 AC Adaptor,
  • KP-30 microUSB Cable,
  • CS-151 Carrying Case,
  • CR-21 Docking Station,
  • Olympus Dictation Management System (ODMS) License (Dictation Module)

How do I configure my DS-9500 to use a WiFi network?

DS-9500 WiFi Selection (Video)

How do I set up my email profile in the DS-9500?

Open the Dictation Module
Connect the DS-9500 recorder.
Click on Tools then click on Options and click on Device.
Select Email Profile
Click Add
Select the email account type.
Select web based mail if you have one of the specified email accounts.
Select SMTP if you have any other email accounts and enter your email address, password and the SMTP server details.
Select the email provider.
Enter a profile name.
Select the Author ID to use.
The Author ID must be configured in the Workflow tab.
Enter the Email Address and Password
Depending on the email provider you use, you may need to enable “allow less secure apps.”
Click Finish
You can repeat this process to register up to 10 email profiles on the recorder.

What are the best settings to maintain battery life?

Enhance Battery Life on your DS-9500 (Video)

How do I set up the device PIN?

PIN Setup:

Go to “device security”
Set a pin lock for the device If this is the first time configuring the pin the “old pin” is 0000 by default
Enter new pin
Check “Enable Device Lock Function…” Box
Select options for when you would like the device to lock
Device Security (Video)

What kind of operating system does the DS-9500 use?

The DS-9500 uses an Android operating system to better support Wi-Fi connectivity.
